Cable & Connectors
A B C D E F G H I J K L M N O
3 GHz F Attenuator Pad
Model No. dB Value Price
The ProSNS™ connector family CT-PPFAM-3 3 Call for Pricing/each
• This family includes F, RCA and BNC universal connectors for series 6 and 59 CT-PPFAM-6 6 Call for Pricing/each
coaxial cables as well as F and BNC connectors for series 11 coaxial cables CT-PPFAM-8 8 Call for Pricing/each
• RGB/mini, plenum, and right angle connectors are also available in CT-PPFAM-10 10 Call for Pricing/each
traditional configurations CT-PPFAM-12 12 Call for Pricing/each
• All ProSNS™ connectors utilize TRUE 360° compression onto the cable providing CT-PPFAM-16 16 Call for Pricing/each
superior RF shielding performance, 85 dB effective shielding (typical on 60% CT-PPFAM-20 20 Call for Pricing/each
bonded foil cable) 1 GHz F Attenuator Pad
• The patented floating-pin insertion guide assists with the insertion of the cable Model No. dB Value Price
into the connector and reduces the insertion force required to provide consistency CT-FAM-3 3 Call for Pricing/each
and easy termination of the connector CT-FAM-6 6 Call for Pricing/each
• An additional O-ring placed at the base of the connector with a NiTin finish and UV CT-FAM-8 8 Call for Pricing/each
resistant plastic provides a reliable, environmentally sealed product on the cable CT-FAM-10 10 Call for Pricing/each
• ProSNS™ RG-11 connectors are designed utilizing an air dielectric for better CT-FAM-12 12 Call for Pricing/each
performance and excellent return loss CT-FAM-16 16 Call for Pricing/each
• Low insertion force is required to compress the connector onto the cable CT-FAM-20 20 Call for Pricing/each
• The improved design offers the flexibility to be installed with nearly all
available compression tools
• Installation requires the industry standard 1/4"-1/4" cable preparation
The ProSNS™ connector family includes F, RCA and BNC universal (fits standard through quad-
shield cable) connectors for series 6 and 59 coaxial cables. RGB/mini, plenum and right angle Voltage Blocking Coupler,
configurations are available in traditional F-Conn® or Snap-N-Seal® configurations. High Return Loss
Color Recommended
Models Description Price Model No. VBC-HR .......................$1.39
Band Tool
RG-59 standard through quad-shield cable
A FSNS59U Universal F Connector Call for Pricing Red CPLCCT-SLM
B FSNS59BNCU Universal BNC Connector Call for Pricing Red CPLCCT-SLM
C FSNS59RCAU Universal RCA Connector Call for Pricing Red CPLCCT-SLM
RG-6 standard through quad-shield cable
D FSNS6U Universal F Connector Call for Pricing Green CPLCCT-SLM Inline Coax Wideband Attenuator
E FSNS6BNCU Universal BNC Connector Call for Pricing Green CPLCCT-SLM Pad, Power-Passing, 30 Db Value,
F FSNS6RCAU Universal RCA Connector Call for Pricing Green CPLCCT-SLM DC-03,000 MHz
G FSNS6PL F connector for plenum cable Call for Pricing Green CPLCCT-SLM Model No. FAMP-20 ......................$2.19
RG-11 standard through quad-shield cable
Universal F Connector for RG-11 standard
H 716SNS1P11H Call for Pricing Black CPLCCT-S59/11
through quad-shield cable, 7/16” Nut
I 716SNS1P11HPLA F Connector for RG-11 Plenum cable, 7/16" Nut Call for Pricing Gray CPLCCT-S59/11 While we attempt to hold pricing
J 716SNS1P11HQ F Connector for RG-11 quad-shield cable, 7/16" Nut Call for Pricing Purple CPLCCT-S59/11 we can not control if our vendors
Universal F Connector for RG-11 standard increase pricing.
K SNS1P11H-9/16 Call for Pricing Black CPLCCT-S59/11
through quad-shield cable, 9/16” Nut
L 90SNS1P11H Right angle F Connector Call for Pricing Black CPLCCT-S59/11 Images shown may be
M FSNS11HBNC Universal BNC Connector Call for Pricing Black SNSUNI different from actual product.
N FSNS11HBNCPLA BNC Connector for RG-11 Plenum cable Call for Pricing Gray SNSUNI
O FSNS11QHBNC BNC Connector for RG-11 quad-shield cable Call for Pricing Purple SNSUNI
