Product ID: CMTS EDGE 32
Supplier: Blonder Tongue
Description: The CMTS Edge, a best-in-class CMTS, supports DOCSIS 3.1, 3.0, and 2.0, using a powerful Marvell Octeon™ network processor with hardware acceleration. The CMTS Edge is built upon a stable and proven Linux operating system to deliver the industry’s best performance, scalability, security, and reliability. Compact in a 1RU footprint, the CMTS Edge makes mounting simple and takes up minimal space in a data center. The dual redundant power supplies also provide valuable uptime protection.
The CMTS Edge 32 supports 32 DS and 8 US channels. A maximum of 1 Gbps is supported, when using higher-order modulation and 6 Mhz channel widths.
The CMTS Edge 32 also supports an optional full-spectrum OFDM downstream channel for DOCSIS 3.1 modems that works simultaneously with the 32 DOCSIS 3.0 SCQAM channels. The CMTS Edge 32 Plus is an upgrade to the CMTS Edge 32 that merely requires a license change to enable mixed-mode DOCSIS 3.1/3.0 downstream operation with up to 8 ATDMA upstream channels.
KEY FEATURES
Description: The CMTS Edge, a best-in-class CMTS, supports DOCSIS 3.1, 3.0, and 2.0, using a powerful Marvell Octeon™ network processor with hardware acceleration. The CMTS Edge is built upon a stable and proven Linux operating system to deliver the industry’s best performance, scalability, security, and reliability. Compact in a 1RU footprint, the CMTS Edge makes mounting simple and takes up minimal space in a data center. The dual redundant power supplies also provide valuable uptime protection.
The CMTS Edge 32 supports 32 DS and 8 US channels. A maximum of 1 Gbps is supported, when using higher-order modulation and 6 Mhz channel widths.
The CMTS Edge 32 also supports an optional full-spectrum OFDM downstream channel for DOCSIS 3.1 modems that works simultaneously with the 32 DOCSIS 3.0 SCQAM channels. The CMTS Edge 32 Plus is an upgrade to the CMTS Edge 32 that merely requires a license change to enable mixed-mode DOCSIS 3.1/3.0 downstream operation with up to 8 ATDMA upstream channels.
KEY FEATURES
- DOCSIS/EuroDOCSIS 3.1/3.0/2.0 compatible
- Compact 1RU 19” chassis
- Hot swap dual redundant power supplies
- Intuitive web-based GUI
- Command line interface via serial/SSH/Telnet
- Integrated cable modem load balancing
- Real time CM/CPE statistics
- QoS support
- Multicast IP video in Edge QAM mode
- Internal DHCP/TFTP server
- Support for external provisioning DHCP/TFTP
- Dual-Stacked IPv4/IPv6 compatibility
- VLAN tagging via option 60
- L2/L3 DHCP relay
- SFP+ 10GbE / Fast-Ethernet / Serial front panel
- Mixed-Mode feature supports simultaneous operation of DOCSIS 3.1 and 3.0 cable modems
