Data & Networking

MikroTik CCR2116-12G-4S+ Cloud Core Router

• 4 - 10G SFP+ Ports
• 16-Core, 2GHz Arm CPU
• 16GB DDR4 RAM
• M.2 PCIE Slot
• Power Consumption – 60W
• Dual-Redundant Power Supply Specifications

The MikroTik CCR2116 with four 10G SFP+ ports has a separate, CPU/ CPU architecture AL73400 2GHz/ ARM 64bit
full-duplex line connected to the Marvell Amethyst family switch CPU core count 16
chip. 12 Gigabit Ethernet ports are running through the Marvel chip. Size of RAM 16GB
And there is another Gigabit port connected directly to the CPU. RAM type DDR4
For management purposes. Each group of 4 ports has a separate Storage 128MB, NAND
full-duplex connection to the switch chip. No bottlenecks here. You Number of 1G Ethernet ports 13
4
Number of 10G SFP+ ports
can expect switch-like throughput in most setups. Number of M.2 slots 1
The new generation of processors offers mind-blowing perfor- Operating System RouterOS (License level 6)
mance. Compared to the MikroTik CCR1036 - the powerhouse with Switch Chip Model 98DX3255
a 36 core CPU, the new MikroTik CCR2116 Router can easily double Dimensions 17.44" x 7.83" x 1.73"
the performance. 16 cores vs 36 cores. Double the performance. (443 x 199 x 44 mm)
There is also an M.2 PCIe slot. It supports SSD`s up to 8 terabytes. Operating Temperature -4 to 140°F (-20 to +60°C)
This could be extremely useful for all kinds of Container apps. But Number of AC Inputs 2
MikroTik is very excited to see what kinds of interesting use-cases AC Input Range 100V - 240V
you will come up with. If you are a rather large ISP, dealing with dy- Power Adapter Nominal Voltage 12V
namic routing, massive BGPs, complex firewall rules, and intricate Power Adapter Nominal Current 10.8A
quality of service configurations. This is the right device for you. Max Power Consumption (Without Attachments) 60W
Max Power Consumption
72W
Model No. CCR2116-12G-4S+ ...........................Call for Pricing Certifications CE, FCC, IC

Indoor 802.11ac 2x2:2 Wi-Fi Access Point
• Wi-Fi Standards • IEEE 802.11a/b/g/n/ac
• Supported Channels
• 2.4GHz: 1-13
• 5GHz: 36-64, 100-144, 149-165
• Concurrent dual band 802.11ac AP, no power adapter

The Ruckus R500 802.11ac indoor access point delivers the ideal combination of capacity, reliability, and affordability for medium-density
locations. It’s the only 802.11ac AP in its class that includes patented Ruckus antenna optimizations and interference mitigation
technologies—the same ones used in our premier highdensity APs—in a low-profile form factor, at a competitive price.
Model No. R500 ..............................................Call for Pricing

Need help designing your wireless distribution system?

Send us a completed site survey and our engineers will provide a complete list of required parts.
Scan the QR code or download the survey from the link below.
http://www.northamericancable.com/techinfo/techtools/nacewlansitesurvey.pdf
