P. 115
Data & Networking
Easily Beam LAN Signal Between
Structures Across Your Sites
5 GHz High-Capacity Wireless Device
Features
• Ultra high performance • 24V Gigabit Ethernet
point-to-multipoint system port (passive PoE)
• 500Mbps capacity • User-friendly interface
• State of the art RF design
DLB 5-15AC
This device is an ideal solution for capacity demanding applications.
State of the art RF design with great output power and sensitivity
parameters improve range and capacity over the highest modula-
tion - 256 QAM. The 24V Gigabit Ethernet port (passive PoE) allows
utilizing the full capacity of the radio when used in a point-to-point or
point-to-multipoint network design. This device is backwards com-
patible with LigoDLB devices using iPoll mode, which helps to expand
or upgrade existing networks using the latest technologies over time.
A. Model No. DLB-5-15AC ...........................................$131.84
Wall Mount for DLB-5-15AC
DLB 5-20AC The DLB Wall Mount is a mounting kit for the
5 GHz Outdoor Long Range PTMP Wireless Bridge, 5 GHz 802.11ac LigoDLB Series, which allows users to install
(2x2:2) 500 Mbps+ Throughput with IPOLL and ATPC. Gigabit DLB wireless devices onto walls. The wall
Ethernet Interface, Integrated 20 DBI Antenna And IP65 24 V PoE mount is designed for quick and effortless
Injector Included. installation of DLB 5-20ac, 5-20n, 5-15ac,
B. Model No. DLB-5-20AC ...........................................$147.69 5-15n, 5-90n, and 5-90ac devices.
Distance Recommendations Model No. MB-DLB-WALLMOUNT ..................................$12.67
PTMP mode 5 km/ 3.11 mi Universal Wall Mount Kit, Compatible
PTP mode 7 km/ 4.35 mi with Small Point To Point and Sector
Wireless Antennas
WLAN standard IEEE 802.11 a/n/ac, iPoll 3 The MT-QM quick mount is a basic wall mount
Radio mode MIMO 2 x 2 adapter for small point to point and sector anten-
Radio 5 GHz models: 5.150 - 5.850 GHz nas. 35 mm tube diameter, Max. wt: 1.5 kgs.
Frequency Band FCC 5.150 - 5.250 and 5.725 - 5.850 GHz)
Transmit power Up to 30 dBm (country dependent) Model No. MT-QM ..........................................................$6.00
Channel size 5, 10, 20, 40, 80 MH Environmental
802.11 a/n: OFDM (64-QAM, 16-QAM, QPSK, BPSK)
Modulation Operating
802.11 ac: OFDM (256-QAM, 64-QAM, 16-QAM, QPSK, BPSK) Temperature -40 - 149 °F (-40 - 65 °C)
802.11 ac @ 40 MHz: 400, 360, 300, 270, 240, 180, 120, 90, 60, 30 Mbps
Data rates
802.11 ac @ 80 MHz: 866, 780, 650, 585, 520, 390, 260, 195, 130, 65 Mbps Humidity 0 - 90 % (non-condensing)
Error Correction FEC, LDPC Management
Duplexing Time division duplex System
Antenna Monitoring SNMP v3, Syslog, Web UI, WNMS
Type Integrated dual-polarized directional panel antenna Configuration WebUI, WNMS
Gain 15 dBi
Wired Regulatory
Interface 10/100/1000 Base-T, RJ45 Certification FCC/IC/CE
Power Physical
24 VDC passive PoE Dimensions 6.2" x 3.8" x 1.5" (158 x 97 x 38 mm)
Power Supply
(AC to 24 VDC adapter is included in the package) Weight 0.4 lbs (185 g)
Power Source 100 – 240 VAC Power consumption (max) 10 W Mounting Pole mounting bracket included
800.688.9282 | sales@nace.tv | nace.tv 113
