Commercial A/V
High Definition HDMI® Splitter & Amplifier Series
Features
• Splits HDMI Inputs to 2, 4 or 8 HDMI outputs • Housed in attractive, low profile casings
• Identical signal quality on all outputs • Designed with the quality conscious
• Multiple units can be cascaded to customer in mind
provide more outputs • Affordably priced
• Perfect for residential or commercial
applications
HDMI Splitter, 1 Input, 4 Output
Model No. CT-HDVD-MINI1X4SPL ..........................$59.00
HDMI 1 × 2 Splitter
Features
• HDMI 1.4b and HDCP 1.4 compliant • Supported audio formats:
• Supports video resolution up to • DTS-HD/Dolby-true-HD/LPCM 7.1/DTS/
4K×2K@30Hz Dolby-AC3/DSD
• Supports 3D video format • Compact design for easy and
• Supported color depths: 30-bit, flexible installation
36-bit and 48-bit/pixel
This HDMI Splitter can distribute 1 HDMI input signal source to 2 HDMI displays simultaneously. Supported video resolution is up to
4K×2K@30Hz. It supports digital audio formats: DTS-HD/Dolby true-HD/LPCM 7.1/DTS/Dolby-AC3/DSD. The product supports HDMI
signal input debounce and output amplification functions and is perfectly compatible with all current HDMI source devices and display
devices.desired HDMI source for display on the HDTV. It can be widely used in digital entertainment centers, control centers,
conference rooms, schools and corporate training environments.
HDMI Splitter, 1 Input, 2 Output
Model No. CT-HDVD-MINI1X2SPL-V2 ....................$30.00
4K HDMI 5 Port Switch HDMI & IR Control
Features Signal Extender
• HDCP 2.2/1.x and Transmit HD Signals
DVI 1.0 compliant with Audio & Infrared
• Support 18Gbps video Control Over a Single Cat5e/6
bandwidth Features
• HDR, HDR10, Dolby Vision and HLG are supported • Distributes HDMI & bi-directional infrared control over a
• Support video resolution up to 4K2K@50/60Hz YCbCr 4:4:4 single Cat5e or Cat6 4 Pair cable
• Support 3D video format • Extends transmission distance up to 330ʹ from sources
• Low power consumption up to 1080p
• Support IR remote control and panel button control • No settings or adjustments required
• Compact design for easy and flexible installation • Uses a single UTP LAN cable (CAT-5e/6)
The 4K HDMI 5 Port Switch can switch any of the 5 HDMI sources • HDCP compliant
to 1 HDMI display. Supported video resolution up to 4K2K@50/ • Uncompressed HDMI video signal
60Hz YCbCr 4:4:4. This product supports HDR, HDR10, Dolby
Vision, and HLG (Hybrid Log-Gamma). It supports all 3D video • Supports full HD 1080p @ 60Hz, 3D, 4K x 2K
formats. Boasting a low power consumption and small form • Supports CEC, 24bit Deep Color
factor, this device can be controlled via the front panel button or • Supports LPCM audio and compressed DTS-HD, Dolby®True HD
remote control included in the box. Fully supports HDCP content • Powered over network cable, only requires a power supply
protection pass-through. at one end (either transmitter or receiver)
4K HDMI 5 Port Switch HDMI & IR Control Signal Extender
Model No. CT-HDVD-5X1-MINI .................................... $37.50 Model No. CT-HDEXT-330-B ..................... Call for Pricing/pair
