Amplifiers, Splitters & Indoor Taps
870 MHz, 30 dB Gain Amplifier With Active Return
Features
• 30 dB Forward gain • Forward gain & slope control
• 54-870 MHz Forward bandwidth • Reverse gain control
• 20 dB Reverse gain • 10 dB Forward gain control range
• 5-42 MHz Reverse bandwidth
The CTA-30-870AR is a commercial quality amplifier with 30 dB of forward gain across a bandwidth of 54 - 870 MHz. This amplifier
was designed for the indoor amplification of CATV signals as well as UHF/VHF signals. The output of the CTA-30-870AR is
easily adjusted using the front panel gain control with 10 dB of gain control range. With separate gain controls for forward and reverse
levels, the CTA-30-870AR can easily be adjusted to maximize performance.
Model No. CTA-30-870AR ..........................................$149.99
1,000 MHz, 35 dB Gain Amplifier With Passive Return
Features
• 35 dB Forward gain • Passive return path
• 54-1,000 MHz Forward bandwidth • Forward gain & slope control
• 5-42 MHz Reverse bandwidth • 16 dB Forward gain control range
The CTA-35-1000PR is a commercial quality amplifier with 35 dB of forward gain
across a bandwidth of 54 - 1,000 MHz. This amplifier was designed for the indoor
amplification of CATV signals as well as UHF/VHF signals. The output of the CTA-35-1000PR is easily adjusted using the front panel
gain control with 16 dB of gain control range. With input and output test ports, the CTA-35-1000PR can easily be adjusted to maximize
performance without disrupting service.
Model No. CTA-35-1000PR .........................................$151.99
Broadband Indoor Distribution Amplifier
Features
• Selectable 30 dB / 40 dB forward gain
• 28 dB Reverse gain
• 42 / 54 MHz split
• 54 - 1,002 MHz Forward bandwidth, • Optimized power consumption: Approx. 20% less when con
5 - 42 MHz reverse bandwidth figured as 30dB FWD/-3dB RET.
• Front panel variable gain and slope controls • Cast chassis with large heat sinks providing exceptional
for easy adjustment. heat dissipation.
• Two-way capability with a user selectable • Exceptional conducted and radiated interference
active/passive return path. performance at full output level.
• Power doubling technology for distortion free, • Enclosure provides excellent shielding performance,
high output level operation. reducing leakage and ingress.
• Externally accessible -20 dB input/output test ports provide • Built-in, high quality switched power supply.
convenient in-service performance monitoring. Model No. TV-451280 ............................................... $339.00
Broadband Distribution Amplifier, Indoor, +35 Db Gain,
5-1,000Mhz, Wall Mount
• 35dB gain,5-1,000 MHz
• Gain control range of 20dB forward and reverse paths
• Wall mountable
• For rack mount equivalent model, review item: RMDA-1000-30, CTA-30RK-1000
Model No. TDA-35-1000 ............................................ $174.99
