P. 121
Meters & Tools
Coaxial Cable Radial
Crimping Tool, RG59/6
Compatible Radial And Double
Bubble Multimedia Connectors
• Required tool for RG59/6-WR and Digital / Analog RF
Signal Level Meter
RG59/6-NR series radial connectors
• Robust blue handle • Direct input by frequency
grips ezEX-RJ45™ connectors from 54 MHz - 870 MHz
The CPLCRBC-BR is a high-grade crimping tool which is compat- • Direct input by channel number
ible with Belden (360) degree radial crimp and double bubble • DVB average power measurement
connector series. This crimp tool features a self-adjusting plunger • Measures Analog, 8VSB, QAM
head which allows a true, secure, and permanent (360) degree 64/256, DVB-C, BER & MER
compression crimp every time. This tool has a variety of fixed • Simultaneously displays video
compression dies with the tool to accommodate F, RCA, and BNC carrier and audio carrier strength,
connector types across PVC, plenum, and mini cable jacket types. and V/A measurement
Model No. CPLCRBC-BR ..................... $115.29
• Switchable between
Locking RF Terminator dBmV and dBµV
Removal Tool • Tilt measurement of three user
These are tools used for the definable channels
unlocking of CTP-59C and other • Carrier-to-noise ratio measurement
compatible manufacturer locking termi- • Trunk voltage measurement
nator units. In some environments open F connections are
closed with a locking terminator, such as the CTP-59C, to avoid • Large 2 5/8" x 1 3/4" dot matrix LCD display with back light
any illegal coaxial connection and signal theft. A locking termina- • Battery powered handheld model with internal NiMH
tor is the item used to accomplish this, 4" Long or 7" long options. battery and included charger
4" Long • Battery life = 5 hours
Model No. CT-904 .........................................................$12.99
7" Long
Model No. LTL-7 .............................................................$17.99 The CT-DLM870D is a handheld signal level meter that is de-
signed to provide the most valuable features at reduced cost.
Double Gang Plastic Outlet Boxes with It performs fast and efficiently to take carrier amplitude mea-
Adjustable Screw Mounts surements. It can also take the direct power measurement of
Model No. CT-LVB-DBL DVB signals. This unit simultaneously displays video carrier,
Quantity 1-9 10-99 100-499 500+ audio carrier strength, V/A measurements, Tilt measurement,
Price Call for Pricing/each C/N measurement and Trunk voltage measurement. This unit is
Single Gang Plastic Outlet Boxes with perfect for balancing digital QAM and analog headend systems,
reading digital off air signal levels, troubleshooting RF distribution
Adjustable Screw Mounts systems and taking measurements at individual drops. With the
Model No. CT-LVB-SGL ability to read individual audio and video carriers along with line
Quantity 1-9 10-99 100-499 500+ voltage and carrier to noise levels, the CT-DLM870D is perfect for
Price Call for Pricing/each all levels of installers and technicians.
Digital / Analog signal level meter
Model No. CT-DLM870D ......................................... $759.00
Replacement power supply
Model No. CT-DLM870D-PS .......................................$19.99
Replacement battery
Post construction bracket to hold a single gang wall plate when Model No. CT-DLM870D-BATT .................................. $42.99
no box is present behind the wall. Wall plate mounts securely to Interconnect cable to connect CT-DLM870D to a PC
CT-4101. Model No. CT-DLM-CABLE .........................................$10.00
Model No. CT-4101 (MP-4101) ...................................... $.79
800.688.9282 | sales@nace.tv | nace.tv 119
