Page 153 - NACE T128 Full catalog_Web
P. 153
Fiber Optic Equipment
L-Band Satellite Transmission Over Fiber Optic Cable
• 5 L-Band Satellite Inputs, 200-2,500 MHz • 4 dBm Fiber output
• Minimum RF Input: -40 dBm • Stand alone housing
• Maximum RF Input: -20 dBm • Low power consumption
• 1 Single-Mode fiber output, SC/APC • AGC Circuitry
• Internal CWDM combiner, 1610-1510nm
Foxcom has taken the field tested quality you’ve come to expect in our AL5 Chassis Mount equipment and placed them in a small-footprint,
wall mountable housing. With options that include the ability to distribute up to 5 L-band signals on a single fiber, the Compact Series may well
be the solution you’ve been looking for. TheBsmarTV compact series of transmitters is designed for deployments in both small and medium
buildings.The AL5T3 compact series of transmitters are low profile and wall mountable providing a cost effective method of delivering trans-
port for small and medium distribution systems where communication room space is at a premium or rack mounting is not an option.
16 Output transmitter kit, includes 1 AL5T3-1-CWDM-5, 1 Fiber 32 Output transmitter kit, includes 1 AL5T3-1-CWDM-5, 1 Fiber
jumper, 1 1x16 fiber splitter & 1 4 slot LGX style housing jumper, 1 1x32 fiber splitter & 1 4 slot LGX style housing
A. Model No. AL5T3-5-CWL-16K .......................Call for Pricing B. AL5T3-5-CWL-32K .......................................Call for Pricing
Fiber Optic Splitters
19" Rack Mountable Fiber Optic Splitters
Models Description Price
FT-RMSME-1X2-SCAPC PLC-Splitter-Rack-Mountable 19", SC/APC, SM, 1 x 2 $114.60
FT-RMSME-1X4-SCAPC PLC-Splitter-Rack-Mountable 19", SC/APC, SM, 1 x 4 $122.10
FT-RMSME-1X8-SCAPC PLC-Splitter-Rack-Mountable 19", SC/APC, SM, 1 x 8 $137.10
FT-RMSME-1X16-SCAPC PLC-Splitter-Rack-Mountable 19", SC/APC, SM, 1 x 16 $205.50
FT-RMSME-1X2-LCAPC PLC-Splitter-Rack-Mountable 19", LC/APC, SM, 1 x 2 $120.00
FT-RMSME-1X4-LCAPC PLC-Splitter-Rack-Mountable 19", LC/APC, SM, 1 x 4 $129.00
FT-RMSME-1X2-FC PLC-Splitter-Rack-Mountable 19", FC, SM, 1 x 2 $114.60
FT-RMSME-1X4-FC PLC-Splitter-Rack-Mountable 19", FC, SM, 1 x 4 $122.10
FT-RMSME-1X2-ST PLC-Splitter-Rack-Mountable 19", ST, SM, 1 x 2 $114.60
FT-RMSME-1X4-ST PLC-Splitter-Rack-Mountable 19", ST, SM, 1 x 4 $122.10
Fiber Optic Splitters, Box Modules ( with Connectors) Fiber Optic Splitters, Box Modules ( with Connectors)
Models Description Price Models Description Price
FT-SBMSE-1X2-SCAPC PLC-Splitter-Box Module, SC/APC, SM, 1 x 2, 1.5M $73.50 FT-SBMSE-1X2-FC PLC-Splitter-Box Module, FC, SM, 1 x 2, 1.5M $72.00
FT-SBMSE-1X4-SCAPC PLC-Splitter-Box Module, SC/APC, SM, 1 x 4, 1.5M $79.50 FT-SBMSE-1X4-FC PLC-Splitter-Box Module, FC, SM, 1 x 4, 1.5M $78.00
FT-SBMSE-1X8-SCAPC PLC-Splitter-Box Module, SC/APC, SM, 1 x 8, 1.5M $93.00 FT-SBMSE-1X2-ST PLC-Splitter-Box Module, ST, SM, 1 x 2, 1.5M $72.00
FT-SBMSE-1X16-SCAPC PLC-Splitter-Box Module, SC/APC, SM, 1 x 16, 1.5M $156.00 FT-SBMSE-1X4-ST PLC-Splitter-Box Module, ST, SM, 1 x 4, 1.5M $78.00
FT-SBMSE-1X2-LCAPC PLC-Splitter-Box Module, LC/APC, SM, 1 x 2, 1.5M $75.00 FT-SBMSE-1X2-SC PLC-Splitter-Box Module, SC, SM, 1 x 2, 1.5M $72.00
FT-SBMSE-1X4-LCAPC PLC-Splitter-Box Module, LC/APC, SM, 1 x 4, 1.5M $81.00 FT-SBMSE-1X4-SC PLC-Splitter-Box Module, SC, SM, 1 x 4, 1.5M $78.00
Fiber Optic Splitters with Wall Box Enclosures
Models Description Price
FT-SWBSME-1X2-SCAPC PLC-Splitter-Wall-Box, SC/APC, SM, 1 x 2 $143.70
FT-SWBSME-1X4-SCAPC PLC-Splitter-Wall-Box, SC/APC, SM, 1 x 4 $151.50
FT-SWBSME-1X8-SCAPC PLC-Splitter-Wall-Box, SC/APC, SM, 1 x 8 $166.50
FT-SWBSME-1X2-LCAPC PLC-Splitter-Wall-Box, LC/APC, SM, 1 x 2 $147.00
FT-SWBSME-1X4-LCAPC PLC-Splitter-Wall-Box, LC/APC, SM, 1 x 4 $156.00
