Off-Air Antennas & Accessories

Off-Air Antenna Amplifier, Smartkom, Filters, Mixes, And Processes
Up To 3 Separate VHF or UHF Off-Air Antennas, Auto or Manual
Programming Via Bluetooth, 54-88 / 174-216 / 470-608 MHz

• Automatic gain regulation of signal in each filter (AGC)
• Plug&Play: the amplifier automatically programs and adjusts the channel
level by pressing the auto programming button.
• Indoor power supply included, with a Bluetooth antenna for wireless
manual programming of the amplifier

SmartKom Off-Air Antenna Amplifier Processes Up To 3 Separate VHF or UHF Off-Air Antennas, Auto or Manual Programming Via Blue-
tooth, (54-88 / 174-216 / 470-608)MHZ Compact and intelligent amplifier with digital channel processing, designed for installation outdoors
or indoors in family houses. Equipped with (3) inputs to amplify terrestrial signals (VHF+UHF) in which each channel can be individually
filtered by any of the (32) available programmable filters. SmartKom is supplied with a 12V (750mA) domestic power supply that is inserted
into the coaxial installation and powers it through its output connector. The auto-programming function of the amplifier gives this device
the ability to program and adjust by itself, simply by pressing a button. In addition, thanks to the Bluetooth antenna included in the PSU,
manual programming of the amplifier can be done wirelessly using a smartphone or tablet, with the ASuite application.
Model No. TV-531981 ........................................Call for Pricing

Off-Air Antenna, Outdoor/Rooftop Model, Broadband
VHF/UHF/FM, 65 Active Elements, 168.25" Boom Length
• 64 Active Elements, 35 UHF Elements, 29 VHF Elements
• Boom length: 168.25"
• Includes hardware to mount unit to a mast (masting sections not included)
• Coaxial cabling not included
• 75 Ohm F connection interface
• Shipping weight: 17 lbs
• Maximum Width: 53.5"
This rooftop antenna to receives over the air VHF/UHF/FM free to air broadcast signals, the manufacturer rates this antenna with a 70 mile VHF
compatibility, and a 60 mile UHF compatibility. This antenna is for outdoor use only and should not be mounted indoors.
Model No. HD-7698P ........................................Call for Pricing

Off-Air Antenna, Outdoor/Rooftop Model, Broadband VHF/UHF/FM

• Active Elements • Includes hardware to mount unit
5016-CM - 15 to a mast (masting sections not included)
5018-CM - 17 • Coaxial cabling not included
5020-CM - 28 • 300 Ohm connection interface,
• Boom length 75 Ohm transformer included
5016-CM - 50" • Weight
5018-CM - 74.5" 5016-CM - 6 lbs
5020-CM - 109" 5018-CM - 10 lbs
5020-CM - 11.5 lbs
These antennas are a rooftop antenna to receive over the air VHF/UHF/FM free to air broadcast signals with UHF/VHF gain rated at 7.0 dB.
This antenna has been specifically tuned for reception of UHF and VHF channels within the range of 54-216 MHz and 470-700 MHz. The
manufacturer rates this antenna with a 45 mile compatibility, this antenna is for outdoor use only and should not be mounted indoors.

15 Active Elements, 50" Boom Length 17 Active Elements, 74.5" Boom Length 28 Active Elements, 109" Boom Length
Model No. 5016-CM ............Call for Pricing Model No. 5018-CM ............Call for Pricing Model No. 5020-CM ...........Call for Pricing

800.688.9282 | sales@nace.tv | nace.tv 93
