P. 118
Meters & Tools
RJ-45 Connectors & Tools
B
A C A
A. EZ-RJ45® CAT 5/5e and CAT 6+ Connectors
The new patented EZ-RJ45 Connector simplifies twisted pair termi-
nations by allowing the wires to be inserted through the connector
and out the front. This allows the technician to easily verify the proper
wiring order. Electrical performance of the termination is optimized by B
pulling the connector down over the cable jacket and seating it tightly
in the rear of the connector. By reducing the distance between the
wire twists and contacts, performance is optimized! EZ-RJ45®Crimp Tool
A. Model No. 100004C..................................................$57.69
EZ-RJ45®CAT 5/5e Connectors -Pack of 50
Model No. 100003C ........................................$30.00/50 pack EZ-RJPRO® HD Crimp Tool
B. Model No. 100054C ..................................................$79.00
EZ-RJ45®CAT 5/5e Connectors -Jar of 100
Model No. 202003J .......................................... $56.79/100 jar
EZ-RJ45®CAT 5/5e Connectors -Pack of 500
Model No. 105003 ......................................$273.90/500 pack SealSmart™ PROCON
EZ-RJ45® CAT 6+ Connectors -Pack of 50 Compression
Model No. 100010C ........................................$32.69/50 pack • Head rotates to switch
EZ-RJ45® CAT 6+ Connectors -Jar of 100 from RG6Q/6 to RG11/7
Model No. 202010J ..........................................$64.00/100 jar • Connector positioner
rotates to change between F, BNC or RCA
EZ-RJ45® CAT 6+ Connectors -Pack of 500
Model No. 105004 ......................................$308.25/500 pack • Adjustable crimp stroke
• Accommodates all standard compression F,
B. Data Connector, Shielded CAT5E/6 With Internal Ground, BNC, RCA & right angle connectors
EZ-RJ45 Modular RJ45 Plug, 8 Pin/8 Position, EZ Style • Guide rule on side of tool
This model with full shielding provides reduced pair-to-pair crosstalk, • High carbon tool steel frame - built to last
and considerably improved immunity to noise at all frequencies. Model No. 16213C ........................................................$58.89
Pack of 100 Replacement Multi-Head Adapter for 16213C
Model No. 105020 ..............................................$139.00/100 Model No. 16215C ........................................................$12.99
Pack of 50
Model No. 100020C ................................................$71.39/50
C. Data Connector, CAT6A RJ45 Shielded Modular Plug, All-In-One Stripping Tool
10 GBPS, 8 Pin/8 Position, with Liner, Solid Three Prong • Coax (Video) replaceable
Pack of 50 cassette blades are pre-set,
Model No. 106192C ................................................$63.69/50 no adjustment required
• Twisted pair (Data) is • Round cables (Voice) is
Double Ended Coax Stripper adjustable and covers a adjustable and covers a
• Quickly and easily remove the wide range of Cat5e and wide range of telephone
cable jacket and inner conductors in a single step Cat6 cables round and flat satin cables
• Works with RG7/11/213/8 and RG59/6/6 Quad cable types • Multi-conductor cables • Includes braid comb, Velcro,
• Control the cutting depth by the number of rotations • Audio cables for folding the braid back
made around the cable • Built-in cable cutter over the cable jacket
• Preset, no adjustments required
Model No. 15020C ........................................................ $10.39 Model No. 15018C ........................................................$14.00
