ezEX RJ-45 Termination Systems

EXO Crimp Frame® with EXO-EX Die™
EXO Crimp Frame® with EZ-RJ45® Die • Single cycle crimp and flush trim
• EZ-RJ45 Die is easily interchangeable • EXO Die™ is easily interchangeable
®
• Reversible EZ-RJ45 Die for ambidextrous operation • Reversible EXO Die™ for ambidextrous operation
• Connectors lock into tool for correct positioning during crimp • Connectors lock into tool for correct positioning during crimp
• Push button lock for easy storage • Push button lock for easy storage
• Ergonomic comfort grip TPR handles • Ergonomic comfort grip TPR handles
• Compatible with EZ-RJ45 connectors: EZ-RJ45 Cat5e and • Terminates larger cables such as Cat6 and Cat6A
Cat6, Shielded Cat5e and Cat6 connectors (internal and The patented EXO Crimp Frame® with EXO-EX Die™ was
external ground) developed to terminate larger cables and conductors (typically
The patented EXO Crimp Frame with EZ-RJ45 Die was Cat6/6A). EXO Crimp Frame with EXO-EX Die™ is designed for
®
®
developed to terminate the original pass through EZ-RJ45 the ezEX-RJ45 connectors. The ezEX-RJ45 connectors are an
connectors which are a standard in the industry. The EXO Crimp RJ45 pass through connector, developed for larger cables and
Frame highlights a push button lock, ergonomic TPR handles, and conductors. Integrated Hi-Lo stagger for improved performance,
works with the EXO-EX Die™ (P/N 100071C) for terminating one piece design pass through system. The EXO Crimp Frame has
ezEX-RJ45™ connectors. a patented push button lock, ergonomic TPR handles and works
®
EXO Crimp Frame with EZ-RJ45® Die with the EZ-RJ45 Die for terminating EZ-RJ45 connectors
®
EXO Crimp Frame with EXO-EX Die™
®
Model No. 100062C ..................................................... $84.00 Model No. 100061C ..................................................... $84.00
EZ-RJ45 Die for EXO Crimp frame EXO-EX Die for EXO Crimp frame
Model No. 100072C ..................................................... $45.25 Model No. 100071C ..................................................... $45.25
EXO Crimp Frame (Frame only w/o crimp die) EXO Crimp Frame (Frame only w/o crimp die)
®
®
Model No. 100060C .........................................Call for Pricing Model No. 100060C .........................................Call for Pricing
Replacement blade for EZ-RJ45 Die Replacement blade for EXO-EX die
Model No. 100072BL ........................................Call for Pricing Model No. 100071BL .........................................Call for Pricing

ezEX44 Connectors ezEX48 Connectors
This connector is designed for larger cables and This connector is designed for larger cables and
conductors. Features a unique integrated Hi-Lo conductors. Features a unique integrated Hi-Lo
stagger load bar and allows ‘big’ conductors to stagger load bar and allows larger conductors to
pass through the front end of the connector making pass through the front end of the connector making
it easy to verify the wiring sequence before termi- it easy to verify the wiring sequence before termi-
nating. This connector is typically used with Cat6 nating. This connector is typically used with Cat6A
and is terminated with EXO Crimp Frame and EXO- and is terminated with EXO Crimp Frame and EXO-
®
®
EX Die™ (100061C). Cat-5e/6/6A compliant, works EX Die™ (100061C). Cat-6A compliant, works with
with solid or stranded 24-22 AWG conductors. solid or stranded 23-22 AWG conductors.
ezEX44 Connectors - 50/Clamshell ezEX48 Connectors, 50/Clamshell
Model No. 100028C ......................................................$32.79 Model No. 100029C ......................................................$39.79
ezEX44 Connector. 100/Jar ezEX48 Connector. 100/Jar
Model No. 202044J ..................................................... $63.49 Model No. 202048J ..................................................... $76.89
ezEX44 Connectors, Bulk. 500/Bag ezEX48 Connectors, Bulk. 500/Bag
Model No. 105024 ...........................................Call for Pricing Model No. 105025 ...........................................Call for Pricing
