Satellite Distribution Equipment
DIRECTV MFH2™ Single Wire Satellite Distribution System
®
Active SWM Expander Module
Features
Standard Output SWM Module • Holds up to 4 DSWM-30
SWM Module for up to 26 Tuners, Standard Output version for • DSWM provides power to all 6 satellite inputs
properties with home run wiring, Each of the two outputs is • Two power inputs (from PI-29Z)
capable of supplying Signal to 13 tuners.
Requires 1 PI-29Z power supply (sold separately) • Four power outputs (to DSWM-30)
Model No. DSWM-30 ........................................Call for Pricing • Requires 1 PI-29Z power supply for every
two modules (sold separately)
High Output SWM Module • Not compatible with legacy SWM8/16/32 units
SWM Module for up to 26 Tuners, High Output version for • Unused ports are auto terminated
properties with loop through wiring Each of the two outputs
is capable of supplying Signal to 13 tuners. • This unit is suitable for indoor use
Requires 1 PI-29Z power supply (sold separately) Model No. SWM EXPANDR-A-R0-09 ..................Call for Pricing
Model No. DSWM-30HP ....................................Call for Pricing
Outdoor SWM Expander Module
Features
• Holds up to 4 DSWM-30
• DSWM provides power to all 6 satellite inputs
SWM Expander Module to Hold Up to 4 DSWM-30 • Two power inputs (from PI-29Z)
Features • Four power outputs (to DSWM-30)
• Holds up to 4 DSWM-30 • Requires 1 PI-29Z power supply for every two
• Six Satellite Inputs modules (sold separately)
• Two power inputs (from PI-29Z) • Provides LNB Power and can be used as a polarity locker
• Four ground lugs • Not compatible with legacy SWM8/16/32 units
• Wall mountable • Unused ports are auto terminated
• Unused ports are auto terminated • This unit is suitable for outdoor use with
the D2 Lite Enclosure
• Requires 1 PI-29Z power supply for every
two modules (sold separately) Model No. SWM EXPANDR-O-RO-09 .................Call for Pricing
• Will not power the LNB, external polarity locker is required Power Supply/Power Inserter, 21V,
• Not compatible with legacy SWM-8/16/32 units Powers DIRECTV SWiM LNBF Models
• For indoor use Model No. PI-21 .......Call for Pricing
Model No. SWM-EXPNDR-P-R0-09 ....................Call for Pricing
