Commercial Headend Equipment
QAM Modulator / Video Encoder, 8 Component / Composite Inputs, 8 SPTS IP Outputs,
High Definition 1080i, with Digital Video Watermarking
Features
• Accepts 8 HD programs
• Provides 8 SPTS IP outputs
• Configurable to ITU-T J.83 Annex A and B digital QAM formats
• Supports real-time Dolby digital audio encoding
• Supports closed captioning EIA-608 for each of the 8
encoded programs
• Equipped with EAS interface (analog video + L/R audio) and
is compatible with all EAS receivers
The HDE-8C-QAM-IP-DIN 02 accepts up to eight analog programs from audio video sources utilizing component or composite outputs. The
encoder digitizes, MPEG2 encodes each input into a high-definition stream, multiplexes the resulting eight streams, and modulates them
onto four adjacent QAM channels in the 54-1,002 MHz range CATV channels 2-158. The unit additionally offers up to8 SPTS single program
IP transport streams for distribution to IPTV multicast compatible displays or set-top units. The option 02 offers digital video watermarking
for any needed forensic signal inspection requirements, and offers DIRECTV H25 high-definition satellite receiver control. The unit supports
user-defined PSIP configuration, supports closed-captioning, and provides an EAS interface if EAS integration required. This unit is commonly
used in satellite or cable television SD or HD headend modulation racks in conjunction with satellite receivers or CATV set-top boxes.
Model No. HDE-8C-QAM-IP-DIN 02 .....................Call for Pricing
Add Digital Channels To Your Private Cable System!!!
The AQT Converts ATSC Off Air Signals To Digital QAM CATV
8 Channel Off Air/QAM Transcoders
Converts 8 Off air channels to either QAM, IP or both
Features
• Encrypted QAM sources can be mapped to IP MPTS AQT8-IP (8x8VSB/QAM to IP)
or SPTS formats in Pass Through mode for This unit allows the user to create a customized line up from off-air
• Remote PHY and Switch Digital applications and/or cable feeds for IP distribution. The customizable IP output
• Accepts up to eight RF inputs in 8VSB/QAM format contains up to 20 programs with a combination of SPTS and/or
MPTS across eight 8 IP addresses from eight 8 RF input sources.
• Provides one common 8VSB/QAM input port
with an internal active splitter Model No. AQT8-IP................................................Call for Pricing
• 2:1 Multiplex Mode to configure eight ATSC 1.0
off-air channels to four MPTS for QAM
• PSIP manipulation AQT8-QAM/IP (8x8VSB/QAM to QAM/IP)
• Accepts EAS input in ASI or IP formats This unit allows the user to create a line up from off-air and/or
cable feeds for coax or IP distribution. The unit simultaneously
• Supports EAS switching-based on contact closure transcodes eight (8) QAM/8VSB input channels to 8 QAM and 8 IP
trigger, or +5 to +12 VDC input transport streams.
• Comprehensive GUI-based remote monitoring Model No. AQT8-QAM-P ........................................ Call for Pricing
and control via any standard Web browser
