Commercial Headend Equipment

Ideal For Adding a Low Cost Channel Guide

to Your Headend Systems!

Miniature Digital Signage & Media Players

Features
• Plays full-screen presentations of videos up to 1080p,
fixed images & audio files.
• Easy, plug-n-play design makes changing signage
content effortless. No logins or internet connection necessary
• Small footprint fits perfectly behind most display screens
• Internet or secondary source connection is not required
for use as the presentations reside locally
• There is no recurring monthly subscription fee for either unit
• Easy-to-use
• Effortless installation – As simple as connecting a DVD player
• Intuitive GUI is easy to navigate and manage
• Content management is straight forward & instinctive No Monthly Fees!
• Dimensions/Weight: 3" x 2.25" x 0.5", 0.15 lbs. No Internet Connection Required!

The DataTronix Mini Digital Signage Player allows you to display user created presentations that are informative and entertaining.
These simple plug-n-play devices are capable of presenting full-screen slideshows and videos on any HDMI or composite input
monitor. The Mini Digital Signage Player displays media files from a USB storage device or SD card, and does not require internet
connectivity. Simply load your image, audio, or video files onto a flash drive and connect it to the Mini Digital Signage Player. The
size of your presentation is only limited by the storage space of your USB or SD device.
Customize your slideshow presentations with user defined durations of 1, 3, 5 or 10 seconds per slide. Background music can also
be inserted and played during a slideshow. Further customization options include a variety of transitions between images
(vertical and horizontal Persian blinds, mosaics, wipes and random transitions). The small-size unit can be discreetly installed
behind a monitor by using double faced tape, cable ties, or Velcro®. All units come with a remote control for accessing menu
commands. For the clearest HD viewing experience, you can connect to the unit using a CableTronix brand HDMI cable (not included).
A composite video 3.5mm breakout adapter cable is included for SD deployments.

The Mini Digital Signage player is perfect for retail stores, boutiques, hotel lobbies, restaurant entrances, transportation sites,
medical offices, educational institutions, fitness centers and much more.

Technical File Compatibility Specifications Contents Include
• Video Up To 1080P • 1 Signage Player • 1 3.5mm to RCA Cable
MPEG1, MPEG2, MPEG4, H.264, WMV9/VC-1, MJPEG, FLV, MKV • 1 Power Supply • 1 Instruction Manual
• Video Up To 720P RM/RMVB • 1 Remote Control
• Image - JPG, BMP, PNG, GIF
• Audio - MP3, WMA, WAV, AAC, OGG, FLAC,
APE, AC3, ATRA, DTS, RA
• Subtitle - SSA, ASS, SUB, SRT, SMI, IDX+SUM
4GB USB flash drive,
DT-HDMP-1 Miniature Digital Signage Player USB 2.0, keychain style
The DT-HDMP-1 units have HDMI and A/V outputs and ship with
a 3.5mm to composite cable. These units offer HD through the Model No. USB-4GB ...$5.99
HDMI output and SD only through the A/V output.
Model No. DT-HDMP-1........................$89.99
