Page 69 - NACE T128 Full catalog_Web

Commercial Headend Equipment

Upgrade all your analog head-ends to digital

• Far better picture quality - today’s TVs want digital! • Clear QAM broadcast - works with all standard HDTVs
• Signal quality - won’t degrade like analog • All at a cost comparable to today’s analog!
• Simple configuration - add or upgrade channels in minutes

HDb2312 Modulators
12 Channels of Digital Standard
Definition in a 1RU Chassis ...at a cost
comparable to analog modulation
ZeeVee 12 Channel 480i Composite Video Modulator

• Each unit broadcasts 12 video • 12 channels fit on 3 RF frequencies - • Digital quality at 480i - SD sources
sources in 1RU - saving you rack space making your coax infrastructure even deliver stunning performance and full
and money. more capable of delivering all digital quality while respecting
your channels. content broadcast requirements.

HDb2920 HD-SDI Digital Encoder/Modulator
• Two SDI inputs
• Transmit multiple SDI channels over a
QAM or DVB T/C network
• HD-SDI ports have reclocked, amplified
loop-through output
• Faster deployment and configuration with our
Maestro interface • Superior video quality Also Available: HDb 2920i two input
• Added support for an Emergency Alert (EAS) channel, • Dolby Digital audio SDI modulator with simultaneous
QAM and IP outputs
closed captioning, and a bonus information channel • Mission-critical reliability

HDb2840 ZeeVee 4 Channel HDMI Video Modulator
Smarter, High-Density HD Video Distribution Over Coax
ZeeVee’s HDb2840 encoder/modulator converts unencrypted
HDMI video sources such as signage players into digital cable
channels that are broadcast over existing coax cabling to an
unlimited number of HDTVs.
• Distribute HD video throughout your facility • Compatible with any HDTV
• Replace multiple signage players • MPEG2 Video and AC3 Audio Encoding
• Maestro Headend Management Software • QAM Output
• Use Existing Coax Cabling
Optional Accessories:
2 RCA Male to Single RCA Male to
6" Y Adapter 3.5mm Stereo Male Male Cable
2 RCA Female to 6' Length 6' Length
3.5mm Stereo Male Model No. 255-045 Model No. 940
Model No. 10A3-042HF 12' Length 12' Length
Model No. 255-047 Model No. 941

ZeeVee manufactured equipment allows distribution of HD digital signage and HD programming sources using existing broadband coax cabling in
facilities not required to encrypt content. Use in other facilities is prohibited.
